500-05 CC

Closed Circuit Portable Impactor Plant

This plant is designed for smaller-sized jobs that require cubicle spec products from a highly portable crushing and screening plant on one chassis.

Play the Video


Easily transports in one pull. Check with your DOT.

Two-deck inclined screen produces two cubical spec products.

Top-deck retained material is returned to the crusher for further processing.

Hydraulic lift and leveling system enables quick set up and tear down by using the hydraulic run-on legs.

Totally self-contained, reliable diesel/electric or all-electric power. You won’t have to worry about hydraulic leaks and failures shutting you down.

Available in-line electro-magnet removes for transport.

Features the industry’s only LIFETIME ROTOR WARRANTY on its solid-steel, three-bar, sculptured rotor—the industry’s heaviest—to keep you up and crushing.*

*North America only.

500-05 CC Specifications

Impactor UM-05
Operating Length 63' 0" / 19.2M
Gross Weight 90500lbs / 41100kg
Travel Length 57' 0" / 17.4M
Travel Width 11' 0" / 3.4M
Travel Height 13' 6" / 4.1M
For complete technical specifications, download our spec sheet.

500-05 CC Additional Features

  • Features closed-circuit crushing and screening on one chassis.
  • Replaces Jaw/Cone/Screen multi-unit systems for a much lower initial investment while maintaining a high production of cubical spec product. Greatly reduces maintenance and fuel costs and is easily transported.
  • Features unique two-step, 5’ grizzly deck to remove fines before crushing.
  • Includes removable electrical control panel featuring pre-wired receptacles for radial stackers.
  • Features standard grizzly bypass chute and available cross-belt conveyor with flop gate to allow for either removal of the material that passes through the grizzly deck for stockpiling or blending back with the crushed material.
  • Transports easily with the hydraulic retractable return conveyor and folding side conveyor.
  • Manage the feeder speed for complete control of the flow of material into the impactor with Variable Frequency Drive (VFD).
  • Includes wireless remote control for the feeder shutdown and all motor stop.
